Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: FUTE
  • Model Number: FTJT-0224
  • Power Supply: AC
  • Application: Highway
  • Lampshade Material: Toughened glass
  • Lighting Bulbs & Tube: Energy Saving, Energy Saving
  • Product name: High efficiency high power IP65 30W 180W LED outdoor street light
  • Protection Rating: IP65,66
  • Lifespan: up to 50,000 hours
  • Color Temp.(CCT): pure white,warm white,etc
  • Input Voltage: AC85-265V, DC24V
  • CRI (Ra>): 75
  • Lamp Luminous Efficiency (lm/w): 85
  • Lamp Body Material: die-casting Aluminum
  • Pole length: 6-12M

Packaging & Delivery

Packaging Details carton for High efficiency high power IP65 30W 180W LED outdoor street light
Delivery Time 15 days for High efficiency high power IP65 30W 180W LED outdoor



Product Description







30W-180W High power LED lights with Bridgelux or CREE chips

Overview:

LED street light is to be the best choice for outdoor lighting from market feedbacks. Compared with traditional lights, it is very popular with domestic and overseas as its own feature & advantages.

What's more, it got a big progress after several years' development such as, more stable, higher illumination, more energy-saving, lower price to market than before, etc.

Of course, the importance that it is not only help us save energy, but also bring us to "green" environment.





LED street light Features:

1.This model uses the mounting arm which is designed to be rotative for adjusting the mounting angles for reaching the best lighting angle, +90/-90 degrees angle adjustable.
2. Bridgelux 45mil high grade led chips and high quality drivers are used, realizing long-term reliable and stable working without failure and maintenance.
3. IP66 guard level, highly resistant from water and dust.
4. High luminance effect, realizing energy saving by 70% comparing with traditional light source.
5. Power factor over 95%, harmonic distortion rate less than 15%;
6. Amazingly long lifetime over 50,000 hours, one-time investment, long-time payback;
7. Adopt digital constant-power technology, realizing control of LED power;
8. Unique one-time die-casted aluminum shell structure, realizing excellent heat dissipation;
9. Stable LED working point, low temperature rise, low brightness decline.



120W LED street light specifications:



Item Number

FT-LED-120W

Input Voltage

AC85-265V, DC24V

LED Power

120W

Output Voltage

12-48V

LED Chip

72pcs Bridgelux 45mil leds

Output Current

2.65A

LED luminous efficiency

>130lm/W

Lamp Flux

10200-10800lm (Tj=60℃, Ta=25℃)

Power Factor

>0.95

Lamp's Efficiency

>90%

CRI (color rendering index)

>75%

THD

<15%

Light Distribution Curve/Beam Pattern

Bat Wing / Rectangular Beam

Beam Lighting Angle

horizontal 150°, vertical 75°

Color Temperature

5000-6500K (CW); 3000-4000K (WW)

Guard Level

IP66

Working Temperature

-30℃ ~ +70℃

Service Lifespan

50,000hrs

Housing Material

Refrigerant Aluminum

Product Dimension

870*420*120mm

Net Weight

9.3 kgs

Gross Weight

10.3 kgs





Company Information







Jiangsu Fute Lighting Group Co., Ltd. (hereinafter referred to as Fute Group) , established in 1987 and located in Songqiao industrial park in the north suburb of Yang Zhou city, Jiangsu Province, is one of the most professional solar LED outdoor lights & electric LED street lights manufacturers in China. At present Fute Group owns 6 subsidiaries such as Yangzhou Fute Steel Pole Lighting factory, Jiangsu Huaxi New Energy Development Co., Ltd., Jiangsu Jiaying Galvanizing Co., Ltd., which occupies a land area of 137,000 square meters and holds the registered capital of RMB 126.88 million Yuan. Our main products are electric LED street lights, traffic lights, solar street lights, solar garden lights and small and medium solar off-grid or grid-connected generating systems, etc. Since 2002, as a reliable & professional solar lighting solution provider, Fute Group has successfully sold our reliable & cost-effective products to overseas markets such as Middle East, Europe, Africa, South America, etc.









Our Services

Installation

We offer detailed instructions and videos for installation. Besides, FUTE Group can provide onsite installation training and technical assistance free of charge in initial period for large projects of more than 100 poles. However, all the travelling and food & accommodation costs shall be borne by the customer.



After-sale service

a. We will offer technical guidance and repair service for the whole life time of our products.

b. We promise to respond with customer’s questions within 24 working-hours.



Life Time & Warranty

LED lamp & lantern: CREE chips or Bridgelux chips provide super-bright light from little power, need simple thermal management, and last up to 80,000 hours, with a 3-year warranty.

Steel Pole: up to 25 years of long life time, with a 15-year warranty.



FAQ

Q1 : You are a factory, trading company or a third party?

A1 : We are a factory for led solar street light.

Q2 : Can I get some samples?

A2 : It is honored to offer you samples.

Q3 : How does your company do everyday quality control?

A3 : we always attach great importance to quality controlling from the very beginning to the very end .

Q4 : What kind of transportation ways you use ?

A4 : By ocean ,air or express .

Q5 : what’s the most safety terms of payment you offer me?

A5 : T/T ,PAYPAL, WESTERN UNION are available, and you could also choose the best way you are available .

Q6 : What's about the packing details?

A6 : Individual neutral packing for each lamp, and Customized  packing is acceptable .

Q7 : How about your delivery time ? Delivery Terms ?

A7 : 3-5 business days for sample ,order subjects to your quantity.



Feel free to contact me, if you have any questions !

Contact:Nancy Xu

Whatsapp/Wechat/Mobile: +8615252575480
Skype: nancyxu0620

Company website:http://www.ftzm.com
